Bonnie McIntyre leading Penny Lane, Squamish, Canada

Background & Objectives

If you are anything like me, you might spend hours scouring Mountain Project for routes and areas that suit your goals and interests. With well over 100k routes, there is a lot to sift through. Mountain project does offer a Route Finder which filters the routes down based on some search criteria and allows you to sort by popularity. This, no doubt can guide you to the classics... but what about the classics for you?
I used machine learning to optimize a similar tool to return routes that meet your specific tastes!

Data Collection

The key data I needed for my recommender were the explicit ratings that users gave to each route. Furthermore, I wanted to gather as much data about each route as I could for deeper analyses and filters for the recommender app.

First, I needed to compile a list of all routeIDs - a unique identifier that MountainProject assigns to each route. For a userID, I made an API call to MountainProject and get a list of all of the routeIDs which that user had ticked. Similarly, for each routeID, I parsed out all of the userIDs that had rated that particular route. In this way, I was able to bounce back and forth and iteratively expand my set of routeIDs to include most of database.

  • Links to code for the class structure and helper functions.

  • With a list of routeIDs, its relatively straight forward to make an HTML request and get all of the raw HTML associated with each route page. I stored this data in a MongoDB with each route as a document.

  • The Mountain Project API also had some useful data about each route parsed nicely into JSON strings.

Data Processing

I needed to clean and standardize my data to make it useful for my recommender and app. For the app, I needed to map several variables (grades, locations etc.) to a simplified scale to match the filters I chose for my app.

The key to the recommender was to create the RUS file which was a CSV with three columns: `routeID`,`userID`,`star` [code]. Each row contains the star value on a 4-star scale that each user gave to each route. The data in this file can be represented as a sparse user-item matrix. The goal of our recommender is to fill in the missing values in this matrix and thereby predict what a user would rate the climbs that she has not climbed.

Analysis

Matrix Sparsity

The first thing I looked at was the sparsity of our matrix in order to determine the best approach for our recommender system.

Two most ubiquitous types of recommender systems are Content-Based and Collaborative Filtering. Content-based recommender systems focus on the characteristics of the users or items and give you recommendations based on the similarity between them. Model-based collaborative filtering produces recommendations based on the knowledge of users’ attitude to items to recommend items. As it turns out model-based collaborative filtering handles large sparse datasets well and can quickly deliver predictions on-demand which is perfect for this application.

Distribution of Ratings

One important thing to consider is the distribution of the ratings. We have a good distribution of ratings, so this will be helpful for picking up on users' preferences.

Routes with the low star ratings don’t tend have many ratings which makes sense (bad routes aren't climbed often, whereas great climbs get climbed a lot). However, this will have some interesting consequences when we start to consider The Cold Start Problem.

The Cold Start Problem

A cold-start is a user who hasn't rated many items or an item that hasn't been rated by many users. In these situations, our recommender model doesn't have much to work with when making predictions which negatively impacts the performance of our model. We can resolve this issue by setting a threshold and excluding users or items from our model that don't have the requisite number of ratings.

As we might expect, the error for our model improves as we raise the route threshold:

Interestingly however, the model does not improve as we raise the threshold for the number of ratings required for routes to be included in the model. From the scatterplot above recall that many of the low rated routes fall into the region below the threshold. Therefore the model starts to lose useful information about what routes users don't like.

I ended up setting the user threshold to a minimum of 10 routes rated to improve performance. I set the route threshold to three since I felt that routes with fewer ratings than that didn't have reliable info and certainly wouldn't be considered classics and therefore I didn't want them to slip into any top ten recommendations.

Fitting the Model

I used the suprise library to do Singular Value Decomposition and did a bit of grid searching to find the optimal hyperparameters for my dataset. The hyperparameters I focused on were learning rate, regularization rate, and the number of epochs. Due to the size of the dataset, there was a lot of processing power and RAM required to search the grid. I employed several AWS EC2 instances to search different parts of the "grid".

We ended up with a fairly good result with a RMSE of 0.62. We can also see from these violin plots that our predicted ratings trend nicely with the True ratings, especially in the 3/4 star region which is where it counts for our top-10 recommender.

Web application

The last piece of this project was implementing my recommender into a web application. I partnered with a web-developer, Ian Schummann, to build a front-end. When a user selects items from the drop-downs and hits submit a JSON string is generated and sent to a Flask app. The flask app processes this JSON string, filters the route database for the routes that meet the criteria specified, sorts the remaining routes based on the estimated rating and then returns the top 10. The key to this was rolling my recommender model and my filtering variables into a single Python Object which I then pickle and pull into the Flask app. I defined a class JSON_handler to do this.

Big shoutout to OpenBeta for helping me get this application hosted and up and running again!
